Special alloy forging is much more difficult than ordinary carbon steel and low-alloy structural steel. To produce special alloy forgings with geometric dimensions and metallurgical quality that meet the requirements, corresponding technical measures must be taken according to different characteristics. These measures are mainly Including process measures, forging and die design measures, quality control measures, testing of forging performance (based on selection of thermodynamic parameters), simulation of forging process, first piece trial forging, etc. Among the above measures, the process measures that need to be taken are described as follows:

1. Reasonably select the temperature, heating speed and holding time of the blank into the furnace

For special alloys with low thermal conductivity (especially large-sized billets), they should be heated at a low speed with the furnace or preheated in the furnace at 800 ° C ~ 850 ° C and held for a period of time, rather than directly heated in the furnace at the initial forging temperature, and then heated It is heated to the initial forging temperature or transferred to a high temperature furnace at the initial forging temperature; the holding time at the initial forging temperature depends on the alloy, which is generally several times longer than that of alloy structural steel.

Other blanks of aluminum, magnesium, copper and their alloys with higher thermal conductivity than steel can be directly put into the high-temperature furnace, the heating speed can be accelerated and the holding time can be appropriately shortened.

Harvester pusher

2. Properly select the degree of deformation

In view of the characteristics of high alloying degree of special alloys, serious macrosegregation of ingots and forgings, low plasticity and wide critical deformation range, in the forging process, it is necessary to strictly control the degree of deformation of each fire and even the degree of deformation of each stroke of the equipment (deformation degree If it is too large, it may be forged and cracked, and if the degree of deformation is too small, it may fall into the deformation zone, resulting in local grain growth and uneven structure).

3. Strictly control the final forging temperature

In view of the characteristics of high recrystallization temperature and obvious cold work hardening tendency of special alloys, it is necessary to increase or greatly increase the final forging temperature. The forging temperature is about 300°C higher.

4. Reasonably choose the working speed of the forging equipment

For some special alloys that are sensitive to strain rate and slow recrystallization speed, hydraulic presses, mechanical presses and screw presses with lower loading speed should be selected for forging; for high-speed steels with serious mesh fractures, in order to completely crush them For two-shaped broken objects, a forging hammer with high working speed and strong impact force should be selected for forging.

Other agricultural machinery forgings

5. Reasonable selection of forging equipment

For some special alloys with high deformation resistance, slow recrystallization speed and high final forging temperature, compared with the same size of broken indium and low-alloy structural steel parts, it is necessary to choose the ability to see or load 3 to 5 times or more. Large forging equipment.

In the same case, molybdenum, magnesium and steel and their alloys with low deformation resistance should choose smaller equipment.

6. Protect the blank

In view of the characteristics that alloy element depleted layer and bile layer or absorbing harmful gas are easily formed on the surface of special alloy during heating process, under possible conditions, it should be heated in a protective atmosphere, or a protective coating should be used to protect the blank, for example, to give The blanks are coated with protective glass lubricant.

7. Double lubricate the blank and mold

In view of the characteristics of high deformation resistance of special alloys, large equipment energy (load) and narrow forging temperature range, in addition to lubricating molds in accordance with the routine, the blank should also be protected and lubricated to minimize friction and blank temperature drop, so as to reduce the required tonnage of equipment . It is recommended to use glass shield lubricants to protect and lubricate the blanks when forging superalloys, titanium alloys and stainless steels.

Other agricultural machinery forgings

8. Select the process of forging under compressive stress as much as possible

In view of the characteristics of high alloying degree and low plasticity of special alloys, it is recommended to choose the forging process under compressive stress such as extrusion, closed die satin, and closed upsetting and extrusion on the flat forging machine as much as possible.

9. “Strike while the iron is hot”

In view of the characteristics of high final forging temperature and narrow forging temperature range of special alloys, forging workers are required to be skilled and responsive, and every link from the release of the blank to the transfer to forging must be fast and accurate, and try to shorten the forging pairs as much as possible. The purpose of “strike while the iron is hot”.

10. Strictly implement the preheating system of tools and molds

In view of the characteristics of high final forging temperature, narrow forging temperature range and low thermal conductivity of special alloys, which are sensitive to mold chilling, all clamping dies in contact with forgings must be preheated in strict accordance with regulations.

The above is about the forging process of special alloy forgings. Through the processing of the above process, the plasticity, impact toughness, fatigue strength and durability of the forgings have also been improved, and then the final heat treatment of the parts can be obtained. Good comprehensive properties such as required hardness, strength and plasticity.
